4K 120M HDMI KVM Extender by RJ45 Ethernet Cat5e Cat6 Cable Converter TX RX Support USB Mouse Keyboard Extension Touch Screen

Availability:

5 in stock
Add to wishlist
Compare
Compatible Devices Keyboard
Specific Uses For Product video conference, monitoring center, multimedia teaching, home theater
Connector Type Plug In
Color grey
Brand Name Swallow
Finish Type Matte
Item Package Quantity 1
Input Voltage 1E+2 Volts
Current Rating 2 Amps
Power Plug No Plug





Features Support HDMI 1.4/HDCP1.4; Support local loop-out ; Support 120m long distance transmission. Low power consumption, low temperature and high safety; Both the TX and RX support 3.5MM left and right audio output; Support IR control; Support USB mouse and keyboard extension; Specifications: Length of CAT5e/CAT6 cable between Rx and TX:120 meters HDMI Input:4k/1080p/720p/576p/576i/480p/480i HDMI Output :4k/1080p/720p/576p/576i/480p/480i Max bandwidth :340MHz Max baud rate:3×3.4Gbps Input video signal:0.5-1.5Volts p-p Output DDC signal : 5Volts p-p (TTL) Input HDMI cable distance :10m AWG26 HDMI standard cable Output HDMI cable distance :10m AWG26 HDMI standard cable TX Max working current:350mA RX Max working current :200mA Power adapter format :Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A Operating Temperature range :(-15 to +55 Degree C) Operating Humidity range : 5 to 90percentRH (No Condensation) Dimension (L x W x H) :107x105x27.3 (mm) TX Weight :499g RX Weight :494g The Package includes: 1. TX Extender 1pcs 2. RX Extender 1pcs 3. IR cable 1pair 4. 12V/2A DC Power adapter 2pcs 5. User Manual 1pcs

1.650,00 EGP

5 in stock

Compare
Compatible Devices Keyboard
Specific Uses For Product video conference, monitoring center, multimedia teaching, home theater
Connector Type Plug In
Color grey
Brand Name Swallow
Finish Type Matte
Item Package Quantity 1
Input Voltage 1E+2 Volts
Current Rating 2 Amps
Power Plug No Plug





Features Support HDMI 1.4/HDCP1.4; Support local loop-out ; Support 120m long distance transmission. Low power consumption, low temperature and high safety; Both the TX and RX support 3.5MM left and right audio output; Support IR control; Support USB mouse and keyboard extension; Specifications: Length of CAT5e/CAT6 cable between Rx and TX:120 meters HDMI Input:4k/1080p/720p/576p/576i/480p/480i HDMI Output :4k/1080p/720p/576p/576i/480p/480i Max bandwidth :340MHz Max baud rate:3×3.4Gbps Input video signal:0.5-1.5Volts p-p Output DDC signal : 5Volts p-p (TTL) Input HDMI cable distance :10m AWG26 HDMI standard cable Output HDMI cable distance :10m AWG26 HDMI standard cable TX Max working current:350mA RX Max working current :200mA Power adapter format :Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A Operating Temperature range :(-15 to +55 Degree C) Operating Humidity range : 5 to 90percentRH (No Condensation) Dimension (L x W x H) :107x105x27.3 (mm) TX Weight :499g RX Weight :494g The Package includes: 1. TX Extender 1pcs 2. RX Extender 1pcs 3. IR cable 1pair 4. 12V/2A DC Power adapter 2pcs 5. User Manual 1pcs
